GS010 Wireless Boom Angle Sensor
01 · Hình ảnh thiết bị
02 · Tổng quan
The GS010 Wireless Boom Angle Sensor offers four configuration option, a 360º span and out of level options.
- No moving parts, uses electronic chip
- Direct Sequence-Spread Spectrum-Two Way Communication
- Transmission Range: 4,300 feet; 1,300 meters
- Ships as standard with 1-"D" Cell lithium battery, 2-4 years battery life
- Users can replace lithium battery with "D" Cell alkaline battery if lithium replacement battery is unavailable when battery goes low. Battery life is 6 months to 1 year using alkaline
- Stainless steel housing
- Easy calibration, bring boom to zero degrees, angle sensor has leveling light for zero degree calibration. No need to move boom to high angle for calibration
- 3/10th's of a degree resolution
- Potted electronics for increased water proof protection
- Operating temperature: -30F to +180F; -35C to +85
- 2 year warranty against defects
- Sensor can be left hand or right hand cab mounted, will automatically adjust for the side it is installed on
- Ideal for monitoring: Main Boom, Luffing Jib, Live Mast, Barge List Angle, Custom Applications
- Standard operating range is -180 degrees to +130 degrees, barge list angle sensor with a range from -5 degrees to +5 degrees
- Can also be ordered as a 360 degree sensor
